Product background：
This document mainly contains the relevant data of our PRC200A high-voltage connector. The PRC200A high-voltage connector is designed with a rated voltage of 1500VDC and a rated current of 200A. It has a 360 degree shielding function and meets the automotive's demanding waterproof requirements. The optional cable size is: 16mm2 to 25mm2 .The product is mainly used in battery, motor, motor controller and other scenarios. This series of products has good electrical, mechanical and environmental performance, meets the EMC standards of the vehicle, and has a variety of product models to meet different needs.
This document mainly contains the relevant data of our PRC200A high-voltage connector. The PRC200A high-voltage connector is designed with a rated voltage of 1500VDC and a rated current of 200A. It has a 360 degree shielding function and meets the automotive's demanding waterproof requirements. The optional cable size is: 16mm2 to 25mm2 .The product is mainly used in battery, motor, motor controller and other scenarios. This series of products has good electrical, mechanical and environmental performance, meets the EMC standards of the vehicle, and has a variety of product models to meet different needs.
Safety Precautions：
This product is used in high voltage and high current environment;
Please install, use and maintain the product correctly; incorrect use of the product may cause serious injury and loss;
If the product is abnormal, such as being modified or damaged, please do not continue to use it to avoid accidents;
Do not insert or remove the connector when the product is powered on;
Do not overload for a long time to avoid potential safety hazards.
Basic parameters:
| Rated current（DC） | 200A Max. |
| Rated voltage（DC） | 1500V |
| Temperature class | -40°C to +125°C (Including temperature rise) |
| Fire-proof level | UL94 V-0 |
| Service life (times) | 100 Min. |
| Safety protection level | IP68/IP6K9K |
| shield | Have |
| High-voltage interlock（HVIL） | Have |
| Temperature control | Have |
| Key position | 6 types |
